127 Pump Ends
p/n: 029-0020-61-0
In sta llatio n
❑
7 Installation
7.1 OVERVIEW
This section provides general guidelines and recommendations for installing
the pump and bell housing (flywheel) assembly into your engine and chas-
sis.
7.2 FRAME MOUNTING
See separate Section, “Drawing Package” on page 133, located at the back
of this manual, for the required mounting specifications. The installation
drawing provides mounting configurations with bolt down specifications.
IMPORTANT!
TO FULLY SUPPORT THE PUMP, GEARBOX OR PEDESTAL ASSEMBLY, ETC.,
USE ALL MOUNTING BOLT HOLES PROVIDED, AS ILLUSTRATED ON THE
INSTALLATION DRAWING. SEE SEPARATE SECTION, “DRAWING PACKAGE”
ON PAGE 133,
WARNINGS !
THE HALE PUMP END ASSEMBLIES ARE HEAVY AND BULKY. ADDING
ACCESSORIES INCREASES THE WEIGHT. CHECK YOUR BILL OF LADING
FOR THE APPROXIMATE WEIGHT. BE CERTAIN TO USE PROPER LIFTING
SUPPORT DEVICES (I.E., OVERHEAD CRANE, JACK, CHAINS, STRAPS,
ETC.) CAPABLE OF HANDLING THE LOAD WHEN REMOVING OR INSTALL-
ING THE PUMP AND GEARBOX ASSEMBLIES.
BE SURE TO WEAR SAFETY GLASSES WHEN REMOVING AND/OR INSTALL-
ING FORCE (PRESS) FITTED PARTS. FAILURE TO COMPLY MAY RESULT IN
SERIOUS EYE INJURY.
ALL FASTENERS ON THE HALE PUMP END ASSEMBLIES ARE SELECTED
FOR THEIR APPLICATION. HALE PRODUCTS DOES NOT RECOMMEND
REPLACING FASTENERS WITH ANYTHING OTHER THAN HALE PART NUM-
BERS PROVIDED. REPLACING WITH A WEAKER ALTERNATIVE POSES A
SERIOUS SAFETY RISK.
ALL FASTENERS MUST BE INSTALLED WITH A LOCKING ANAEROBIC
ADHESIVE/SEALANT, SUCH AS LOCTITE® #246 FOR GEARBOX AND #242
FOR PUMP.
