❑ Installation
128 Pump Ends
p/n: 029-0020-61-0
Wherever there is a requirement for new parts, it is recommended to use
only Hale authorized replacement parts for optimum safety of the equip-
ment and its operators and to reduce unnecessary “downtime.”
General Mounting
Tapped holes of various sizes and depths are provided, dependent on pump
model and layout requirements. Mounting also varies depending on assem-
bly configuration, i.e.,
❑ Horizontal
❑ Vertical
❑ Inverted mount
❑ Standard engine rotation (clockwise)
❑ Opposite engine rotation (counterclockwise)
Ensure that:
❑ All bolts are tight. Use a torque wrench to torque bolts to the manufac-
turer's (engine) recommended specifications.
❑ Bolts used are “Grade 5” strength MINIMUM.
7.3 PLUMBING CONNECTIONS
See separate Section, “Drawing Package” on page 133, located at the back
of this manual, for the required plumbing specifications. The appropriate
plate drawing provides available plumbing specifications, both standard and
optional.
For example:
❑ Suction, victaulic and/or flange-type
❑ Discharge, typically flange-type
Various flanges and manifolding are also available. Contact Hale Products
at 610-825-6300 for additional information.
7.4 FLUID LEVELS
To meet various shipping regulations, ALL fluids within the pump, gearbox
and pedestal assemblies are drained prior to shipping from the factory.
