Data modules and asynchronous data units
555-233-116 68 Issue 4 October 2002
Enabling test mode on 7400A DCE
The test-mode (pin 25) setting can have either of two values: ON or OFF (the
default).
1. Accept the default values, unless otherwise instructed. When the SET TM
LEAD? prompt appears, press the NEXT/NO button to keep the default,
ON.
Exiting menus and saving changes on 7400A DCE
1. When the DONE? prompt appears, press the ENTER/YES button.
2. When the SAVE CHANGES? prompt appears, press the ENTER/YES
button.
Your changes are saved.
SET TM LEAD?
DATA NEXT/NO BACK ENTER/YES
● ➜ ● ❍ ❍
Push the button indicated by the arrow ( ➜ )
DONE?
DATA NEXT/NO BACK ENTER/YES
● ❍ ❍ ➜ ●
Push the button indicated by the arrow ( ➜ )
SAVE CHANGES?
DATA NEXT/NO BACK ENTER/YES
● ❍ ❍ ➜ ●
Push the button indicated by the arrow ( ➜ )
CHANGES SAVED
DATA NEXT/NO BACK ENTER/YES
● ❍ ❍ ➜ ●
Push the button indicated by the arrow ( ➜ )
