Contents
555-233-116 10 Issue 4 October 2002
8 Terminal server installation 121
■ Overview 121
■ Installing and administering the terminal server 122
Administering the IOLAN+ 124
Potential failure scenarios and repair actions 131
■ Administering IP node names 131
■ Administering IP services 132
9 DS1/T1 CPE loopback jack 135
■ Installing a loopback jack 135
With a smart jack 135
Without a smart jack 136
■ Administering the loopback jack 137
■ Loopback testing with a smart jack 137
Testing the DS1 span from the ICSU to the loopback jack 137
Testing the DS1 span from the smart jack to the
network interface termination or fiber multiplexer (MUX) 143
Testing the DS1 span from the loopback jack to
the smart jack 143
■ Testing a loopback jack without a smart jack 151
Configurations using fiber multiplexers 156
10 ISDN converters and adapters 157
■ Converters for single-carrier cabinets 158
PRI-to-DASS and PRI-to-DPNSS converters 158
PRI-to-BRI converter 159
■ Converters for multi-carrier cabinets 160
PRI-to-DASS and PRI-to-DPNSS converters 160
PRI-to-BRI converter 161
