Connector and cable pinout charts
555-233-116 234 Issue 4 October 2002
Plug 01
47 R-O LI (High) 11 R-O LI (High)
22 O-R L I 03 O-R L I
48 R-G LO 09 R-G LO
23 G-R LO (High) 01 G-R LO (High)
Table 31. DS1 interface Cable H600-307
50-Pin 15-Pin
Pin Color Designation Pin Color Designation
02 W-BL
03 BL-W
47 W-G LI (High) 11 W-G LI (High)
22 G-W LI 03 G-W LI
48 W-BR LO 09 W-BR LO
23 BR-W LO (High) 01 BR LO (High)
49 W-SL LOOP2 07 W-SL LOOP2
24 SL-W LOOP1 05 SL-W LOOP1
All other pins empty.
Table 30. DS1 interface cable H600-348 — Continued
50-Pin 15-Pin
Pin Color Designation Pin Color Designation
Continued on next page
