Connector and cable pinout charts
Issue 4 October 2002 233 555-233-116
45 V-G 48 312
47 G-V 23 212
47 V-BR 49 313
48 BR-V 24 213
49 V-SL 50 300
50 SL-V 25 200
Table 30. DS1 interface cable H600-348
50-Pin 15-Pin
Pin Color Designation Pin Color Designation
Plug 04
38 W-BL LI (High) 11 W-BL LI (High)
13 BL-W LI 03 BL-W LI
39 W-O LO 09 W-O LO
14 O-W LO (High) 01 O-W LO (High)
Plug 03
41 W-G LI (High) 11 W-G LI (High)
17 G-W LI 03 G-W LI
42 W-BR LO 09 W-BR LO
17 BR-W LO (High) 01 BR-W LO (High)
Plug 02
44 W-SL LI (High) 11 W-SL LI (High)
19 SL-W LI 03 SL-W L I
45 R-BL LO 09 R-BL LO
20 BL-R LO (High) 01 BL-R LO (High)
Continued on next page
Table 29. Lead and color designations — Continued
Cross-Connect Pin Color
Amphenol
Pin Backplane
Pin
Continued on next page
