Paradyne COMSPHERE 3810 Plus and 3811 Plus
Issue 4 October 2002 101 555-233-116
Paradyne COMSPHERE 3810 Plus and
3811 Plus
Configuring the 3810 Plus and 3811 Plus modems
1. Install the modem as described in the vendor’s documentation.
2. Attach a PC with terminal emulation software, as described in the vendor’s
documentation.
3. From the terminal, enter the following AT command string:
AT&F&D2&S4\D3S2=128x7V2S7=60S85=1
4. Then enter the following command string:
ATY0S10=100S78=2M0E0\N1&W
The modem is now configured.
Paradyne COMSPHERE 3910
You configure COMSPHERE 3910 modems using a front button panel (see
Figure 20 ) or Hayes-compatible AT commands. For instructions on how to
physically connect the modem and general configuration instructions, see the
documentation that came with the modem. This document describes configuring
the 3910 for particular, DEFINITY adjuncts.
Figure 20. COMPSPHERE 3910 modem, front panel
F1 F2 F3
Power On Selftst
Passed
modf3150 KLC 030899
