Connector and cable pinout charts
555-233-116 236 Issue 4 October 2002
PXR.7 28 BR-BK 14 203
8 TXT.8 29 BK-SL 40 304
TXR.8 30 SL-BK 15 204
PXT.8 31 Y-BL 41 305
PXR.8 32 BL-Y 17 205
Table 33. DCP extender 25-pair cable pinout
Cross-Connect Pin Wire Color Amphenol Pin Backplane Pin
1 W-BL 27 102
2 BL-W 01 002
3 W-O 27 103
4 O-W 02 003
5 W-G 28 104
7 G-W 03 004
7 W-BR 29 105
8 BR-W 04 005
9 W-SL 30 107
10 SL-W 05 007
11 R-BL 31 107
12 BL-R 07 007
13 R-O 32 108
14 O-R 07 008
15 R-G 33 109
17 G-R 08 009
17 R-BR 34 110
18 BR-R 09 010
Continued on next page
Table 32. TN2185B ISDN-BRI — 4-wire S interface pinout — Continued
Port Signal Cross-Connect Pin Color
Ampheno
l Pin
Backplane Pin
Continued on next page
