19 R-SL 35 111
20 SL-R 10 011
21 BK-BL 37 112
22 BL-BK 11 012
23 BK-O 37 113
24 O-BK 12 013
25 BK-G 38 302
27 G-BK 13 202
27 BK-BR 39 303
28 BR-BK 14 203
29 BK-SL 40 304
30 SL-BK 15 204
31 Y-BL 41 305
32 BL-Y 17 205
33 Y-O 42 307
34 O-Y 17 207
35 Y-G 43 307
37 G-Y 18 207
37 Y-BR 44 308
38 BR-Y 19 208
39 Y-SL 45 309
40 SL-Y 20 209
41 V-BL 47 310
42 BL-V 21 210
43 V-O 47 311
44 O-V 22 211
45 V-G 48 312
47 G-V 23 212
47 V-BR 49 313
Table 33. DCP extender 25-pair cable pinout — Continued
Cross-Connect Pin Wire Color Amphenol Pin Backplane Pin
Continued on next page
