Page 207: Chapter 18
Issue 4 October 2002
207
555-233-116
18
Multimedia communications
products: MMCX, MMCH, ESM
This chapter provides information on connecting the following equipment to:
■
MASI for MMCX
■
Wideband endpoints
■
Multimedia call handling (MMCH)
NOTE:
The information in this chapter does not apply to the G700 Media Gateway
configurations.
MASI for MMCX
The multimedia application server interface (MASI) enables the DEFINITY ECS to
provide calling features to the MultiMedia Communications eXchange (MMCX).
The MMCX server connects to the Avaya Media Server through a D8W cable.
See
for pin locations.
Table 24.
D8W cable modular pin assignments
Pin Signal
Pin
Signal
1
Receive ring
5
Transmit Tip
2
Receive tip
7
No connection
3
No connection
7
No connection
4
Transmit ring
8
No connection
