Paging and announcement equipment
555-233-116
200
Issue 4 October 2002
Figure 50.
Multi-site environment
, an S8700 Media Server in a multi-connect configuration (top middle)
is networked with an S8300 Media Server in a G700 Media Gateway (bottom left)
and a DEFINITY CSI (bottom right).
In this multi-site environment, there are a number of standalone solutions
networked together using protocols such as QSIG or DCS. Each location has its
own processing capability and separate managed configurations. These
configurations can be a mix of different solutions. This configuration can also
support video, modem, and other non-audio functionalities.
Configuration using the S8700 Media Server with
IP connect
NOTE:
The S8700 Media Server with a G600 Media Gateway is called an
“IP connect” configuration.
LAN
LAN
LAN
LAN
cydcmse LJK 032402
PSTN
PSTN
WAN
