Prospector Series Poppet Valves
VAL-12-8 Littleton, CO USA Phone: 303-794-2611 www.norgren.com
2-Port/2-Position (2 way) Inline, Normally Open
Below listed operators have non-locking override and 110/120V 50/60Hz coil.
Symbol Solenoid Basic Port Model Operating Pilot Weight Repair Kit§
Pilot Size Size Pressure Pressure lbs. (kg)
psig (bar) psig (bar)
Internal Pilot 1/4" B1012C-00-CY
30 - 150 30 - 150 2.22
53474-03
(2.1 - 10.3) (2.1 - 10.3) (1.01)
3/8" B1013C-00-CY
30 - 150 30 - 150 2.22
53474-03
(2.1 - 10.3) (2.1 - 10.3) (1.01)
1/2"
1/2" B1014C-00-CY
30 - 150 30 - 150 2.22
53474-03
(2.1 - 10.3) (2.1 - 10.3) (1.01)
3/4" B1015C-00-CY
30 - 150 30 - 150 2.22
53474-03
(2.1 - 10.3) (2.1 - 10.3) (1.01)
3/4" B1025C-00-CC
30 - 150 30 - 150 4.40
53475-01
(2.1 - 10.3) (2.1 - 10.3) (2.00)
1"
1" B1026C-00-CC
30 - 150 30 - 150 4.40
53475-01
(2.1 - 10.3) (2.1 - 10.3) (2.00)
1-1/4" B1027C-00-CC
30 - 150 30 - 150 4.40
53475-01
(2.1 - 10.3) (2.1 - 10.3) (2.00)
External Pilot 1/4" B1012H-00-CY
0 - 150 30 - 150 2.22
53474-03
(0 - 10.3) (2.1 - 10.3†) (1.01)
3/8" B1013H-00-CY
0 - 150 30 - 150 2.22
53474-03
(0 - 10.3) (2.1 - 10.3†) (1.01)
1/2"
1/2" B1014H-00-CY
0 - 150 30 - 150 2.22
53474-03
(0 - 10.3) (2.1 - 10.3†) (1.01)
3/4" B1015H-00-CY
0 - 150 30 - 150 2.22
53474-03
(0 - 10.3) (2.1 - 10.3†) (1.01)
3/4" B1025H-00-CC
0 - 150 30 - 150 4.40
53475-01
(0 - 10.3) (2.1 - 10.3†) (2.00)
1"
1" B1026H-00-CC
0 - 150 30 - 150 4.40
53475-01
(0 - 10.3) (2.1 - 10.3†) (2.00)
1-1/4" B1027H-00-CC
0 - 150 30 - 150 4.40
53475-01
(0 - 10.3) (2.1 - 10.3†) (2.00)
† External Pilot Supply: Pilot supply pressure must be equal to or greater than the operating pressure.
§ Repair
Kit: Kits contain all elastomers necessary to service one valve body.
OUT
B
A
IN
OUT
B
A
IN
