Prospector Series Poppet Valves
VAL-12-40
Littleton, CO USA
Phone: 303-794-2611
www.norgren.com
Symbol
Pilot
Basic Port
Model
Operating Pilot
Weight
Repair
Kit§
Type
Size
Size
Pressure
Pressure
lbs.(kg)
psig (bar)
psig (bar)
Internal
1/4"
F1012C-00-MB
30 - 300
30 - 300
2.37
53473-05
Pilot
1/4"
(2.1 - 20.7)
(2.1 - 20.7)
(1.08)
3/8"
F1013C-00-MB
30 - 300
30 - 300
2.37
53473-05
(2.1 - 20.7)
(2.1 - 20.7)
(1.08)
3/8"
F1023C-00-MB
30 - 300
30 - 300
2.89
53474-06
(2.1 - 20.7)
(2.1 - 20.7)
(1.31)
1/2"
1/2"
F1024C-00-MB
30 - 300
30 - 300
2.89
53474-06
(2.1 - 20.7)
(2.1 - 20.7)
(1.31)
3/4"
F1025C-00-MB
30 - 300
30 - 300
2.89
53474-06
(2.1 - 20.7)
(2.1 - 20.7)
(1.31)
3/4"
F1035C-00-MB
30 - 300
30 - 300
6.00
53475-06
(2.1 - 20.7)
(2.1 - 20.7)
(2.73)
1"
1"
F1036C-00-MB
30 - 300
30 - 300
6.00
53475-06
(2.1 - 20.7)
(2.1 - 20.7)
(2.73)
1-1/4"
F1037C-00-MB
30 - 300
30 - 300
6.00
53475-06
(2.1 - 20.7)
(2.1 - 20.7)
(2.73)
External
1/4"
F1012H-00-MB
0 - 300
30 - 300
2.37
53473-05
Pilot
1/4"
(0 - 20.7)
(2.1 - 20.7†)
(1.08)
3/8"
F1013H-00-MB
0 - 300
30 - 300
2.37
53473-05
(0- 20.7)
(2.1 - 20.7†)
(1.08)
3/8"
F1023H-00-MB
0 - 300
30 - 300
2.89
53474-06
(0 - 20.7)
(2.1 - 20.7†)
(1.31)
1/2"
1/2"
F102CH-00-MB
0 - 300
30 - 300
2.89
53474-06
(0 - 20.7)
(2.1 - 20.7†)
(1.31)
3/4"
F1025H-00-MB
0 - 300
30 - 300
2.89
53474-06
(0 - 20.7)
(2.1 - 20.7†)
(1.31)
3/4"
F1035H-00-MB
0 - 300
30 - 300
6.00
53475-06
(0 - 20.7)
(2.1 - 20.7†)
(2.73)
1"
1"
F1036H-00-MB
0 - 300
30 - 300
6.00
53475-06
(0 - 20.7)
(2.1 - 20.7†)
(2.73)
1-1/4"
F1037H-00-MB
0 - 300
30 - 300
6.00
53475-06
(0 - 20.7)
(2.1 - 20.7†)
(2.73)
Subbase
1/2"
1/2"
F2214C-00-MB
30 - 200
30 - 200
4.55
53474-06
(2.1 - 13.8)
(2.1 - 13.8)
(2.07)
Internal
1"
1"
F2226C-00-MB
30 - 200
30 - 200
10.21
53475-06
Pilot
(2.1 - 13.8)
(2.1 - 13.8)
(4.64)
Subbase
1/2"
1/2"
F2214H-00-MB
0 - 200
30 - 200
4.55
53474-06
(0 - 13.8)
(2.1 - 13.8†)
(2.07)
External
1"
1"
F2226H-00-MB
0 - 200
30 - 200
10.21
53475-06
Pilot
(0 - 13.8)
(2.1 - 13.8†)
(4.64)
CYL2 CYL1
IN EXH
CYL2 CYL1
IN EXH
CYL2 CYL1
IN EXH
4
-Port/2-Position (4 way) Inline & Subbase
B
elow listed operators are palm button, spring return mechanical operators.
* Thread: Insert A for Inline BSPP; 1 for Inline PTF; or B for Inline ISO Rc; 4 for Subbase valve with subbase, BSPP; 5 for Subbase valve without subbase, BSPP; 2 for Subbase valve
with subbase, PTF; 3 for Subbase valve without subbase, PTF; 6 for Subbase valve with subbase, ISO Rc; or 7 for Subbase valve without subbase, ISO Rc.
† External Pilot Supply : Pilot supply pressure must be equal to or greater than the operating pressure.
§ Spares Kit: Kits contain all elastomers necessary to service one valve body.
