Prospector Series Poppet Valves
Solenoid Pilot Operated Spring Return Inline and Subbase Valves
2-Port/2-Position (2 way) Inline, Normally Closed
Below listed operators have non-locking override and 110/120V 50/60Hz coil.
† External Pilot Supply: Pilot supply pressure must be equal to or greater than the operating pressure.
§ Repair
Kit: Kits contain all elastomers necessary to service one valve body.
Symbol Solenoid Basic Port Model Operating Pilot Weight Repair Kit§
Pilot Size Size Pressure Pressure lbs. (kg)
psig (bar) psig (bar)
Internal Pilot 1/4" A1012C-00-CY
30 - 150 30 - 150 2.12
53474-03
(2.1 - 10.3) (2.1 - 10.3) (1.01)
3/8" A1013C-00-CY
30 - 150 30 - 150 2.22
53474-03
(2.1 - 10.3) (2.1 - 10.3) (1.01)
1/2"
1/2" A1014C-00-CY
30 - 150 30 - 150 2.22
53474-03
(2.1 - 10.3) (2.1 - 10.3) (1.01)
3/4" A1015C-00-CY
30 - 150 30 - 150 2.22
53474-03
(2.1 - 10.3) (2.1 - 10.3) (1.01)
3/4" A1025C-00-CC
30 - 150 30 - 150 4.40
53475-01
(2.1 - 10.3) (2.1 - 10.3) (2.00)
1" A1026C-00-CC
30 - 150 30 - 150 4.40
53475-01 1"
(2.1 - 10.3) (2.1 - 10.3) (2.00)
1-1/4" A1027C-00-CC
30 - 150 30 - 150 4.40
53475-01
(2.1 - 10.3) (2.1 - 10.3) (2.00)
1-1/2" A1038C-00-CC
30 - 150 30 - 150 4.40
53822-01
(2.1 - 10.3) (2.1 - 10.3) (3.98)
2"
2" A1039C-00-CC
30 - 150 30 - 150 8.76
53822-01
(2.1 - 10.3) (2.1 - 10.3) (3.98)
External Pilot 1/4" A1012H-00-CY
0 - 150 30 - 150 2.12
53474-03
(0 - 10.3) (2.1 - 10.3†) (1.01)
3/8" A1013H-00-CY
0 - 150 30 - 150 2.22
53474-03
(0 - 10.3) (2.1 - 10.3†) (1.01)
1/2"
1/2" A1014H-00-CY
0 - 150 30 - 150 2.22
53474-03
(10 - 10.3) (2.1 - 10.3†) (1.01)
3/4" A1015H-00-CY
0 - 150 30 - 150 2.22
53474-03
(0 - 10.3) (2.1 - 10.3†) (1.01)
3/4" A1025H-00-CC
0 - 150 30 - 150 4.40
53475-01
(0 - 10.3) (2.1 - 10.3†) (2.00)
1" A1026H-00-CC
0 - 150 30 - 150 4.40
53475-01 1"
(0 - 10.3) (2.1 - 10.3†) (2.00)
1-1/4" A1027H-00-CC
0 - 150 30 - 150 4.40
53475-01
(0 - 10.3) (2.1 - 10.3†) (2.00)
1-1/2" A1038H-00-CC
0 - 150 30 - 150 4.40
53822-01
(0 - 10.3) (2.1 - 10.3†) (3.98)
2"
2" A1039H-00-CC
0 - 150 30 - 150 8.76
53822-01
(0 - 10.3) (2.1 - 10.3†) (3.98)
OUT
B
A IN
OUT
B
A
IN
