Prospector Series Poppet Valves

All Dimensions in Inches (mm)

VAL-12-52

Littleton, CO USA

Phone: 303-794-2611

www.norgren.com

Smooth Start Valves Dimensions

Basic 1/2-Inch A00*5A, A00*5B, A00*5C & A00*5D.

1.50 (38.1)

2.06 (52.3)

3.00 (76.2)

1.56 (39.5)

3.06 (77.7)

2.50 (63.5)

3.74 (96.0)

2.28 (57.9)

2.13 (0.84)

Adjustment Screw

2.28 (57.9)

1.66 (42.2)

7.1 (0.28)

Dia. (2 pics)

2.13 (0.84)

1.00 (25.4)

1/4", 3/8", 1/2", 3/4"*

Basic 1-Inch A00*5E, A00*5F & A00*5G.

2.31(58.7)

4.62 (117.3)

3.31 (84.1)

2.06 (52.3)

4.10 (104.1)

1.13 (28.7)

2.88 (73.2)

6.04 (153.4)

3.98 (101.1)

2.73 (69.3)

2.38 (50.5)

Adjustment Screw

10.4 (0.41)

Dia. (2 pics)

3/4", 1", 1-1/4"*

* After final adjustment, drive pin in until flush to make adjustment tamper resistant.
