Prospector Series Poppet Valves
VAL-12-36 Littleton, CO USA Phone: 303-794-2611 www.norgren.com
2-Port/2-Position (2 way) Inline, Normally Open
Below listed operators are palm button, spring return mechanical operators.
Symbol Pilot Basic Port Model Operating Pilot Weight Repair Kit§
Type Size Size Pressure Pressure lbs. (kg)
psig (bar) psig (bar)
Internal
1/4" B1012C-00-MB
30 - 300 30 - 300 2.10
53474-03
Pilot (2.1 - 20.7) (2.1 - 20.7) (0.95)
3/8" B1013C-00- MB
30 - 300 30 - 300 2.10
53474-03
(2.1 - 20.7) (2.1 - 20.7) (0.95)
1/2"
1/2" B1014C-00- MB
30 - 300 30 - 300 2.10
53474-03
(2.1 - 20.7) (2.1 - 20.7) (0.95)
3/4" B1015C-00- MB
30 - 300 30 - 300 2.10
53474-03
(2.1 - 20.7) (2.1 - 20.7) (0.95)
3/4" B1025C-00-MB
30 - 300 30 - 300 4.27
53475-01
(2.1 - 20.7) (2.1 - 20.7) (1.94)
1" B1026C-00-MB
30 - 300 30 - 300 4.27
53475-01 1"
(2.1 - 20.7) (2.1 - 20.7) (1.94)
1-1/4" B1027C-00-MB
30 - 300 30 - 300 4.27
53475-01
(2.1 - 20.7) (2.1 - 20.7) (1.94)
External
1/4" B1012H-00-MB
0 - 300 30 - 300 2.10
53474-03
Pilot (0 - 20.7) (2.1 - 20.7†) (0.95)
3/8" B1013H-00-MB
0 - 300 30 - 300 2.10
53474-03
(0 - 20.7) (2.1 - 20.7†) (0.95)
1/2"
1/2" B1014H-00-MB
0 - 300 30 - 300 2.10
53474-03
(0 - 20.7) (2.1 - 10.3†) (0.95)
3/4" B1015H-00-MB
0 - 300 30 - 300 2.10
53474-03
(0 - 20.7) (2.1 - 10.3†) (0.95)
3/4" B1025H-00-MB
0 - 300 30 - 300 4.27
53475-01
(0 - 20.7) (2.1 - 10.3†) (1.94)
1" B1026H-00-MB
0 - 300 30 - 300 4.27
53475-01 1"
(0 - 20.7) (2.1 - 10.3†) (1.94)
1-1/4" B1027H-00-MB
0 - 300 30 - 300 4.27
53475-01
(0 - 20.7) (2.1 - 10.3†) (1.94)
OUT
B
A
IN
OUT
B
A
IN
† External Pilot Supply: Pilot supply pressure must be equal to or greater than the operating pressure.
§ Spares Kit: Kits contain all elastomers necessary to service one valve body.
