Prospector Series Poppet Valves
VAL-12-24 Littleton, CO USA Phone: 303-794-2611 www.norgren.com
Below listed operators are single air operators with spring returns.
3-Port/2-Position (3 way) Inline, Normally Closed
3-Port/2-Position (3 way) Inline, Normally Open
Symbol Basic Port Model Operating Pilot Weight Repair Kit§
Size Size Pressure Pressure lbs.(kg)
psig (bar) psig (bar)
1/4" D1012H-00-A1
0 - 300 30 - 300 1.20
53474-05
1/4"
(0 - 20.7) (2.1 - 20.7) (0.55)
3/8" D1013H-00-A1
0 - 300 30 - 300 1.20
53474-05
(0 - 20.7) (2.1 - 20.7) (0.55)
1/4" D1022C-00-A1
0 - 300 30 - 300 1.79
53474-03
(0 - 20.7) (2.1 - 20.7) (0.81)
3/8" D1023C-00-A1
0 - 300 30 - 300 1.79
53474-03
(0 - 20.7) (2.1 - 20.7) (0.81)
1/2"
1/2" D1024C-00-A1
0 - 300 30 - 300 1.79
53475-03
(0 - 20.7) (2.1 - 20.7) (0.81)
3/4" D1025C-00-A1
0 - 300 30 - 300 1.79
53475-03
(0 - 20.7) (2.1 - 20.7) (0.81)
3/4" D1035C-00-A1
0 - 300 30 - 300 3.78
53475-01
(0 - 20.7) (2.1 - 20.7) (1.72)
1" 1" D1036C-00-A1
0 - 300 30 - 300 3.78
53475-01
(0 - 20.7) (2.1 - 20.7) (1.72)
1-1/4" D1047C-00-A1
0 - 300 30 - 300 3.78
53475-01
(0 - 20.7) (2.1 - 20.7) (1.72)
Symbol Basic Port Model Operating Pilot Weight Repair Kit§
Size Size Pressure Pressure lbs.(kg)
psig (bar) psig (bar)
1/4" E1012H-00-A1
0 - 300 30 - 300 1.20
53473-05
(0 - 20.7) (2.1 - 20.7) (0.55)
1/4"
3/8" E1013H-00-A1
0 - 300 30 - 300 1.20
53473-05
(0 - 20.7) (2.1 - 20.7) (0.55)
1/4" E1022C-00-A1
0 - 300 30 - 300 1.79
53474-03
(0 - 20.7) (2.1 - 20.7) (0.81)
3/8" E1023C-00-A1
0 - 300 30 - 300 1.79
53474-03
1/2"
(0 - 20.7) (2.1 - 20.7) (0.81)
1/2" E1024C-00-A1
0 - 300 30 - 300 1.79
53474-03
(0 - 20.7) (2.1 - 20.7) (0.81)
3/4" E1025C-00-A1
0 - 300 30 - 300 1.79
53474-03
(0 - 20.7) (2.1 - 20.7) (0.81)
3/4" E1035C-00-A1
0 - 300 30 - 300 3.78
53475-01
(0 - 20.7) (2.1 - 20.7) (1.72)
1" 1" E1036C-00-A1
0 - 300 30 - 300 3.78
53475-01
(0 - 20.7) (2.1 - 20.7) (1.72)
1-1/4" E1047C-00-A1
0 - 300 30 - 300 3.78
53475-01
(0 - 20.7) (2.1 - 20.7) (1.72)
§ Repair Kit: Kit contains all elastomers necessary to service one valve body.
Note: Pilot supply pressure must be equal to or greater than the operating pressure.
EXH IN
OUT
EXH IN
OUT
Normally Open
