Prospector Series Poppet Valves
Symbol
Solenoid Basic Port
Model
Operating Pilot
Weight
Repair
Kit§
Pilot
Size
Size
Pressure
Pressure
lbs. (kg)
psig (bar)
psig (bar)
Internal Pilot
1/4"
F1012C-00-CY
30 - 150
30 - 150
1.91
53477-06
1/4"
(2.1 - 10.3)
(2.1 - 10.3)
(0.87)
3/8"
F1013C-00-CY
30 - 150
30 - 150
1.91
53473-05
(2.1 - 10.3)
(2.1 - 10.3)
(0.87)
3/8"
F1023C-00-CY
30 - 150
30 - 150
2.50
53474-06
(2.1 - 10.3)
(2.1 - 10.3)
(1.13)
1/2"
1/2"
F1024C-00-CY
30 - 150
30 - 150
2.50
53474-06
(2.1 - 10.3)
(2.1 - 10.3)
(1.13)
3/4"
F1025C-00-CY
30 - 150
30 - 150
2.50
53474-06
(2.1 - 10.3)
(2.1 - 10.3)
(1.13)
3/4"
F1035C-00-CC
30 - 150
30 - 150
2.50
53475-06
(2.1 - 10.3)
(2.1 - 10.3)
(1.13)
1"
1"
F1036C-00-CC
30 - 150
30 - 150
4.49
53475-06
(2.1 - 10.3)
(2.1 - 10.3)
(2.04)
1-1/4"
F1037C-00-CC
30 - 150
30 - 150
4.49
53475-01
(2.1 - 10.3)
(2.1 - 10.3)
(2.04)
External Pilot
1/4"
F1012H-00-CY
0 - 150
30 - 150
1.91
53477-06
1/4"
(0 - 10.3)
(2.1 - 10.3†)
(0.87)
3/8"
F1013H-00-CY
0 - 150
30 - 150
1.91
53473-05
(0 - 10.3)
(2.1 - 10.3†)
(0.87)
3/8"
F1023H-00-CY
0 - 150
30 - 150
2.50
53474-06
(0 - 10.3)
(2.1 - 10.3†)
(1.13)
1/2"
1/2"
F1024H-00-CY
0 - 150
30 - 150
2.50
53474-06
(0 - 10.3)
(2.1 - 10.3†)
(1.13)
3/4"
F1025H-00-CY
0 - 150
30 - 150
2.50
53474-06
(0 - 10.3)
(2.1 - 10.3†)
(1.13)
3/4"
F1035H-00-CC
0 - 150
30 - 150
2.50
53475-06
(0 - 10.3)
(2.1 - 10.3†)
(1.13)
1"
1"
F1036H-00-CC
0 - 150
30 - 150
4.49
53475-06
(0 - 10.3)
(2.1 - 10.3†)
(2.04)
1-1/4"
F1037H-00-CC
30 - 150
30 - 150
4.49
53475-01
(0 - 10.3)
(2.1 - 10.3†)
(2.04)
Subbase
1/2"
1/2"
F2214C-00-CY
30 - 150
30 - 150
4.67
53474-06
(2.1 - 10.3)
(2.1 - 10.3)
(2.12)
Internal Pilot
1"
1"
F2226C-00-CC
30 - 150
30 - 150
9.33
53475-06
(2.1 - 10.3)
(2.1 - 10.3)
(4.24)
Subbase
1/2"
1/2"
F2214H-00-CY
0 - 150
30 - 150
4.67
53474-06
(0 - 10.3)
(2.1 - 10.3†)
(2.12)
External Pilot
1"
1"
F2226H-00-CC
0 - 150
30 - 150
9.33
53475-06
(0 - 10.3)
(2.1 - 10.3†)
(4.24)
4-Port/2-Position (4 way) Inline & Subbase
Below listed operators have non-locking override and 110/120V 50/60Hz coil.
† External Pilot Supply: Pilot supply pressure must be equal to or greater than the operating pressure.
§ Repair
Kit: Kits contain all elastomers necessary to service one valve body.
Technical Details for Prospector Solenoid Pilot Operated Valves
Rating
90 - 105% Continuous Duty; and 85 - 105% for CC.
Power Requirements
CC: 8 WDC, 8 WAC. CY: 6 WDC, 7 WAC. (See Options on VAL-12-13).
Electrical Connection
CC: Form A per DIN 43650; CE, CF, CY: Industry Standard Form B per DIN 43650.
Manual Override
Non-Locking (See Options on VAL-12-13)
Protection Class
IP65 (NEMA 4) (See Options on VAL-12-13)
Coil Type
Class H. Molded with 3-pin plug in connector. (See Options on VAL-12-13).
Plug
Cable grips for cables 6 to 8 mm (1/4" to 5/16") in diameter.
CYL2 CYL1
IN EXH
CYL2 CYL1
IN EXH
CYL2 CYL1
IN EXH
