Norgren Prospector Series Datasheets - Manual (Page 31)

All Dimensions in Inches (mm)
Littleton, CO USA Phone: 303-794-2611 www.norgren.com VAL-12-31
Prospector Series Poppet Valves
Valve Body Dimensions – 4-Port/2-Position Inline Bodies
Basic 1/4 - Inch Body F101*C (4-Port/2-Position Pilot Operated Valve)
Basic 1/2 - Inch Body F102*C (4-Port/2-Position Pilot Operated Valve)
Basic 1 - Inch Body F103*C (4-Port/2-Position Pilot Operated Valve)
CYL 2 CYL 1 IN
EX
1.75 (44.5)
.69 (17.5)
3.13 (79.5)
1.56 (39.6)
3.00 (76.2)
1.50 (38.1)
1.22 (31.1)
.66 (16.8) .84 (21.3)
1.15 (29.1)
1.84 (46.7)
.46 (11.7)
2.73 (69.3)
1/4", 3/8"
.59 (15.0)
1/4", 3/8"
3/8", 3/8"
CYL 2 CYL 1 IN
EX
1.50 (38.1)
3.00 (76.2)
3.75 (95.3)
2.00 (50.8)
A
1.69 (42.9)
1.75 (44.5)
1.94 (49.3)
.88 (22.4)
.75 (19.1)
2.75 (69.9)
1.63 (41.4)
3.00 (76.2)
.34 (8.6) Dia. (2 plcs)
3.94 (100.1)
.38 (9.7) TYP
3/8", 1/2", 3/4"
1/2", 3/4", 3/4"
.88 (22.4)
3/8", 1/2", 3/4"
CYL 2 CYL 1
IN
EXH
2.25 (57.2)
4.00 (101.6)
4.50 (114.3)
2.50 (63.5)
.38 (9.7) TYP
5.00 (127.0)
1.25 (31.8)
2.50 (63.5)
3.49 (88.6)
6.23 (158.2)
44.5 (1.75)
88.9 (3.50)
1.44 (36.6)
.41 (10.4)
Dia. (2 plcs)
3.49 (88.6)
2.24 (56.9)
2.50 (63.5)
3/4", 1", 1-1/4"
3/4", 1", 1-1/4"
1", 1-1/4", 1-1/4"
TOP VIEW
