Prospector Series Poppet Valves
All Dimensions in Inches (mm)
VAL-12-32 Littleton, CO USA Phone: 303-794-2611 www.norgren.com
Valve Body Dimensions – 4-Port/2-Position Subbase Bodies
Basic 1/2 - Inch Body F2214C (4-Port/2-Position Pilot Operated Valve)
Basic 1- Inch Body F2226C (4-Port/2-Position Pilot Operated Valve)
EXH IN
CYL 1 CYL 2
3.94 (100.1)
1.56 (39.6) 1.44 (36.6)
.25 (6.4) TYP
4.04 (102.6) 3.50 (88.9)
1.75 (44.5)
.27 (6.9) TYP
1.53 (38.9)
3.03 (77.0)
.53 (13.5)
4.95 (125.7)
1.31(33.3) 1.63 (41.4)
1.56 (39.6)
.81 (20.6)
4.25 (107.9)
1.31 (33.3) 1.63 (41.1) 1.31 (33.3)
.34 (8.6) DIA (2 Plcs)
3.38 (85.9) 4.20 (106.7)
.63 (16.0) TYP
.41 (10.4 )TYP
.28 (7.1) DIA (6 plcs)
.81 (20.6)
1/2", 3/4"
.35 (8.9) TYP
3/4", 3/4"
1/2", 1/2"
VALVE BODY
EXH IN
CYL 1 CYL 2
6.23 (158.2)
2.00 (50.8) 2.31(58.7)
.34 (8.6) TYP
6.09 (154.7)
5.25 (133.4)
2.63 (66.7)
.42(10.7) TYP
3.59 (91.2)
.53(13.5) 1.84 (46.7)
6.75 (171.5)
1.5(38.1) 3.00 (76.2)
2.39 (60.7)
1.06 (26.9)
6.00 (152.4)
1.50 (38.1) 1.50 (38.1) 3.00 (76.2)
.41 (10.4) DIA (4 Plcs)
5.25 (133.4) 6.06 (153.9)
.34 (8.6) DIA (6 Plcs)
.38 (9.7) TYP
1.06 (26.9)
.50 (12.7)
.41 (10.4) TYP
1-1/4", 1"
1"
†Gasket, .03 (.8) thick, included in dimensions.
VALVE BODY
