Prospector Series Poppet Valves
Littleton, CO USA Phone: 303-794-2611 www.norgren.com VAL-12-59
Repair Kits and Factory Installed Fluorocarbon Elastomers
• When requesting repair kits or information for your valve, give both main valve and operator model numbers exactly as found on their respective
nameplates.
• Repair Kits - Repair kits contain all elastomers necessary to service one valve body, operator, or time delay. Order the appropriate valve body,
operator, and time delay repair kit as required to service your valve.
• Valve Bodies and Operators with Factory Installed Fluorocarbon Elastomers - Valve bodies and some operators are available with fluorocarbon
elastomers for use when contaminants in the air system are incompatible with the standard nitrile elastomers. To order valves with fluorocarbon
elastomers, specify the desired valve model number (from the preceding pages plus the Order With numbers given below. Be sure to specify the
Order With number for the valve body and the Order With number for the operator. Fluorocarbon elastomers are not available on Time Delays, on the
A6 Air Operator, or on the standard C Series Solenoid Operators.
Order With
Repair Kit Factory Installed
Fluoro- Fluorocarbon
Type Internal Variation Nitrile carbon Elastomer
A101 B, C, E, F, H, J, K 53474-03 53474-14 53474-21 1EE
A102 B, C, E, F, H, J, K 53475-01 53475-07 53475-13 1F2
A103 B, C, H, J 53822-01 53909-01 53909-03 1F8
B101 B, C, E, F, H, J, K 53474-03 53474-14 53474-21 1EE
B102 B, C, E, F, H, J, K 53475-01 53475-07 53475-13 1F2
C101 B, C, E, F, H, J, K 53474-03 53474-08 53474-15 1E8
C102 B, C, E, F, H, J, K 53474-03 53474-08 53474-15 1E8
C103 B, C, E, F, H, J, K 53475-01 53475-07 53475-13 1F2
C104 B, C, H, J 53822-01 53909-02 53909-04 1F9
C105 B, C, E, F, H, J, K 53474-03 53474-08 53474-15 1E8
C106 B, C, E, F, H, J, K 53474-03 53474-08 53474-15 1E8
C108 B, C, H, J 53822-01 53909-02 53909-04 1F9
D101 B, E, F, H, K 53473-05 53473-06 53473-11
D102 B, C, E, F, H, J, K 53474-03 53474-09 53474-16 1E9
D103 B, C, E, F, H, J, K 53475-01 53475-08 53475-14 1F2
D104 B, C, E, F, H, J, K 53475-01 53475-08 53475-14
D107 B, C, F, H, J 53474-03 53474-24 53474-23
D108 B, C, F, H, J 53475-01 53475-22 53475-21
E101 B, F, H 53473-05 53473-07 53473-12
E102 B, C, F, H, J 53474-03 53474-10 53474-17 1EA
E103 B, C, F, H, J 53475-01 53475-09 53475-15
E104 B, C, F, H, J 53475-01 53475-09 53475-15
F101 B, C, E, H, K 53473-05 53473-08 53473-13 1E5
F101 F 53473-16 53473-08* 53473-13
F102 B, C, E, H, J, K 53474-06 53474-11 53474-18 1EB
F102 F 53474-25 53474-11* 53474-18
F103 B, C, E, H, J, K 53475-06 53475-10 53475-16
F103 F 53475-25 53475-10* 53475-16
F221 B, C, E, H, J, K 53474-06 53474-11 53474-18
F221 F 53474-25 53474-11* 53474-18
F222 B, C, E, H, J, K 53475-06 53475-10 53475-16
F222 F 53475-25 53475-10* 53475-16
F223 B, C, E, H, J, K 53474-06 53474-11 53474-18
F223 F 53474-25 53474-11* 53474-18
F224 B, C, E, H, J, K 53475-06 53475-10 53475-16
F224 F 53475-25 53475-10* 53475-16
F323 B, C, E, H, J, K 53474-06 53474-11 53474-18
F323 F 53474-25 53474-11* 53474-18
F324 B, C, E, H, J, K 53475-06 53475-10* 53475-16
F324 F 53475-25 53475-10* 53475-16
G102 B, C, E, H, J, K 53474-06 53474-12 53474-19 1EC
G102 F 53474-25 53474-12* 53474-19 1EC
G103 B, C, E, H, J, K 53475-06 53475-11 53475-17
G103 F 53475-25 53475-11* 53475-17
Position in Model Number
VALVE BODY TIME DELAY OPERATOR
1 0 2 1 A
4 3 5
C
6 2 1
1 A
10 9
0 0
8 7
Order With
Repair Kit ** Factory Installed
Fluoro- Fluorocarbon
Type Nitrile carbon Elastomer
A1 None Used None Used None Used
A4 None Used None Used None Used
A6 53476-01 — —
CC — — —
CE — — —
CF — — Standard ††
CN — — —
CP — — —
CR — — —
CS — — —
CT — 53478-13 Standard ††
CU — — —
CV — — —
CW — — —
CY — — —
CZ — — Standard ††
C0 53478-01 53478-13 53478-20
C1 53478-01 53478-13 53478-20
C2 53478-04 53478-13 53478-25
C3 53478-04 53478-13 53478-25
C4 53478-01 53478-13 53478-20
C8 53478-01 53478-13 53478-20
DA — — Standard ††
D0 † 53478-02 53478-14 53478-24
D1 † 53478-02 53478-14 53478-24
D2 † 53478-05 53478-16 53478-26
D3 † 53478-05 53478-16 53478-26
D4 † 53478-01 53478-13 53478-20
D5 † 53478-01 53478-13 53478-20
D6 † 53478-04 53478-15 53478-25
D7 † 53478-04 53478-15 53478-25
D8 † 53478-04 53478-15 53478-25
E1 53478-01 53478-13 53478-20
E3 53478-04 53478-15 53478-25
E8 53478-01 53478-13 53478-20
F4 † 53478-02 53478-14 53478-24
F5 † 53478-05 53478-16 53478-26
F6 † 53478-01 53478-13 53478-20
F7 † 53478-04 53478-15 53478-25
M
Series
53769-01 53769-02 53769-03
X0 53478-07 53478-17 53478-19
X1 53478-07 53478-17 53478-19
X2 † 53478-08 53478-18 53478-28
X3 † 53478-08 53478-18 53478-28
X4 † 53478-07 53478-17 53478-19
X5 † 53478-07 53478-17 53478-19
Repair Kit
(Nitrile
Type Only)
01 53477-01
02 53477-01
03 53477-03
04 53477-03
05 Top 53477-01
05 Bottom 53477-03
09 53477-03
10 53477-03
22 Top 53477-03
22 Bottom 53477-03
23 53477-03
24 53477-03
* Order Gasket 53045-02 when ordering fluorocarbon repair kits for main valves with internal variation F.
** Solenoid operator repair kits do not include coils.
†
Order two kits to service these operators.
†† The CF, CT, CZ, and DA operators are equipped with fluorocarbon elastomers.
