Prospector Series Poppet Valves
All Dimensions in Inches (mm)
VAL-12-20 Littleton, CO USA Phone: 303-794-2611 www.norgren.com
Valve Body Operator with Standard Cable Grip Connector
* Gasket 0.03 (0.8) thick included in dimensions.
CC CE, CF, CY
Optional C Series
Conduit Housing
C0, C1
3.00 (76) Dia.
3.30 (84)*
Exhaust Diffuser
Manual Override
1/8" NPT External
Pilot Port
*Gasket 0.03 (0.8) thick included in dimensions
3.00 (76) Dia.
2.93 (74)
3.18 (81)*
Manual Override
1/8" - 27 NPT
External
Pilot Port
1/8" Solenoid Exhaust
1.29 (33)
4.41 (112)
0.79 (20)
1.97 (50)
1.59 (40.4)
Conduit Port
1/2" NPT
.32 (7.9)
Manual
Override
Locking
External Pilot Port
1/8" NPTF
3.00 (76.2)
2.06 (52.3)
3.09 (78.5)*
.34 (8.6)
Optional P Series
.94 (23.9)
3.00 (76.2) Dia.
External Pilot Port
1/8" NPTF
.62 (15.7)
Aux. Outlet - 1/8" NPTF
(Can be used for operating
additional remote valve.)
1.87 (47.5)
4.03 (102.4) AC Oper.
.36 (9.1)
Conduit Port
1/2" NPSM
Exhaust Port
1/8" NPTF
(Do Not Restrict)
P1
