Prospector Series Poppet Valves
Littleton, CO USA
Phone: 303-794-2611
www.norgren.com
VAL-12-35
Manual & Mechanical Operated Spring Return Inline and Subbase Valves
2-Port/2-Position (2 way) Inline, Normally Closed
Below listed operators are palm button, spring return mechanical operators.
† External Pilot Supply : Pilot supply pressure must be equal to or greater than the operating pressure.
§ Spares Kit: Kits contain all elastomers necessary to service one valve body.
Symbol
Pilot
Basic Port
Model
Operating Pilot
Weight
Repair
Kit§
Type
Size
Size
Pressure
Pressure
lbs. (kg)
psig (bar)
psig (bar)
Internal
1/4"
A1012C-00-MB
30 - 300
30 - 300
2.10
53474-03
Pilot
(2.1 - 20.7)
(2.1 - 20.7)
(0.95)
3/8"
A1013C-00-
MB
30 - 300
30 - 300
2.10
53474-03
(2.1 - 20.7)
(2.1 - 20.7)
(0.95)
1/2"
1/2"
A1014C-00-
MB
30 - 300
30 - 300
2.10
53474-03
(2.1 - 20.7)
(2.1 - 20.7)
(0.95)
3/4"
A1015C-00-
MB
30 - 300
30 - 300
2.10
53474-03
(2.1 - 20.7)
(2.1 - 20.7)
(0.95)
3/4"
A1025C-00-MB
30 - 300
30 - 300
4.27
53475-01
(2.1 - 20.7)
(2.1 - 20.7)
(1.94)
1"
A1026C-00-MB
30 - 300
30 - 300
4.27
53475-01
1"
(2.1 - 20.7)
(2.1 - 20.7)
(1.94)
1-1/4"
A1027C-00-MB
30 - 300
30 - 300
4.27
53475-01
(2.1 - 20.7)
(2.1 - 20.7)
(1.94)
1-1/2"
A1038C-00-MB
30 - 300
30 - 300
8.64
53822-01
(2.1 - 20.7)
(2.1 - 20.7)
(3.92)
2"
2"
A1039C-00-MB
30 - 300
30 - 300
8.64
53822-01
(2.1 - 20.7)
(2.1 - 20.7)
(3.92)
External
1/4"
A1012H-00-MB
0 - 300
30 - 300
2.10
53474-03
Pilot
(0 - 20.7)
(2.1 - 20.7†)
(0.95)
3/8"
A1013H-00-MB
0 - 300
30 - 300
2.10
53474-03
(0 - 10.3)
(2.1 - 20.7†)
(0.95)
1/2"
1/2"
A1014H-00-MB
0 - 300
30 - 300
2.10
53474-03
(0 - 10.3)
(2.1 - 10.3†)
(0.95)
3/4"
A1015H-00-MB
0 - 300
30 - 300
2.10
53474-03
(0 - 10.3)
(2.1 - 10.3†)
(0.95)
3/4"
A1025H-00-MB
0 - 300
30 - 300
4.27
53475-01
(0 - 10.3)
(2.1 - 10.3†)
(1.94)
1"
A1026H-00-MB
0 - 300
30 - 300
4.27
53475-01
1"
(0 - 10.3)
(2.1 - 10.3†)
(1.94)
1-1/4"
A1027H-00-MB
0 - 300
30 - 300
4.27
53475-01
(0 - 10.3)
(2.1 - 10.3†)
(1.94)
1-1/2"
A1038H-00-MB
0 - 300
30 - 300
8.64
53822-01
(0 - 10.3)
(2.1 - 10.3†)
(3.92)
2"
2"
A1039H-00-MB
0 - 300
30 - 300
8.64
53822-01
(0 - 10.3)
(2.1 - 10.3†)
(3.92)
OUT
B
A
IN
OUT
B
A
IN
