Prospector Series Poppet Valves
All Dimensions in Inches (mm)
VAL-12-46 Littleton, CO USA Phone: 303-794-2611 www.norgren.com
Basic 1/2 - Inch Body F2214C
(4-Port/2-Position Pilot Operated Valve)
Valve Body Dimensions – 4-Port/2-Position Subbase Bodies
EXH IN
CYL 1 CYL 2
3.94 (100.1)
1.56 (39.6) 1.44 (36.6)
.25 (6.4) TYP
4.04 (102.6) 3.50 (88.9)
1.75 (44.5)
.27 (6.9) TYP
1.53 (38.9)
3.03 (77.0)
.53 (13.5)
4.95 (125.7)
1.31(33.3) 1.63 (41.4)
1.56 (39.6)
.81 (20.6)
4.25 (107.9)
1.31 (33.3) 1.63 (41.1) 1.31 (33.3)
.34 (8.6) DIA (2 Plcs)
3.38 (85.9) 4.20 (106.7)
.63 (16.0) TYP
.41 (10.4)TYP
.28 (7.1) DIA (6 plcs)
.81 (20.6)
1/2", 3/4"
.35 (8.9) TYP
3/4", 3/4"
1/2", 1/2"
Basic 1- Inch Body F2226C
(4-Port/2-Position Pilot Operated Valve)
VALVE BODY SUBBASE
EXH IN
CYL 1 CYL 2
6.23 (158.2)
2.00 (50.8) 2.31(58.7)
.34 (8.6) TYP
6.09 (154.7) 5.25 (133.4)
2.63 (66.7)
.42(10.7) TYP
3.59 (91.2)
.53(13.5) 1.84 (46.7)
6.75 (171.5)
1.5(38.1) 3.00 (76.2)
2.39 (60.7)
1.06 (26.9)
6.00 (152.4)
1.50 (38.1) 1.50 (38.1) 3.00 (76.2)
.41 (10.4) DIA (4 Plcs)
5.25 (133.4) 6.06 (153.9)
.34 (8.6) DIA (6 Plcs)
.38 (9.7) TYP
1.06 (26.9)
.50 (12.7)
.41 (10.4) TYP
1-1/4", 1"
1"
SUBBASE VALVE BODY
