Prospector Series Poppet Valves
VAL-12-14 Littleton, CO USA Phone: 303-794-2611 www.norgren.com
Voltage Options
Specify the desired valve model number (from pages 2, 3 or 5) and note the solenoid operator from the last 2 digits. Use the table below to
obtain options and add the desired option part number to the model number.
For example: order AA025C-00-CY1W4 for a 2-port/2-position, normally closed, internal pilot, Solenoid Pilot Operated spring return valve
with non-locking override using 24V/60Hz optional voltage.
Solenoid Pilot Operated Inline & Subbase Valves
STANDARD SOLENOID
OPTIONAL SOLENOID OPERATORS
OPERATORS
VOLTAGE CC CE, CY CF* C0, C1 X1 P1
12V/60Hz/50Hz — 1W3 — — — —
24V/50Hz 1WC 1W4 1WJ — — 1PG
24V/60Hz 1WC 1W4 1WJ — — 1PH
48V/50Hz — 1W5 — — — —
48V/60Hz — 1W5 — — — 1PF
100V/50Hz — — — Standard Standard —
110V/50Hz Standard Standard 1WH — — Standard
120V/50Hz — — — 1RD 1NF —
120V/60Hz Standard Standard 1WH Standard Standard Standard
220V/50Hz 1WB 1W6 — — — 1PD
240V/60Hz 1WB 1W6 — 1R5 1NH 1PA
440V/50Hz — — — — — 1PE
480V/60Hz — — — — — 1PB
6VDC — — 1WK 1R1 1N7 —
12VDC 1WD 1W1 1WF 1R2 1NA —
24VDC 1WA 1W2 Standard 1R3 1ND —
110VDC — — 1WL — — —
STANDARD SOLENOID
OPTIONAL SOLENOID OPERATORS
OPERATORS
VOLTAGE CC CE, CY CF* C0, C1 X1 P1
12V/60Hz/50Hz — 54452-04 — — — —
24V/50Hz 54458-53 54452-05 54469-04 — — 53761-32
24V/60Hz 54458-53 — 54469-04 — — 53761-33
48V/50Hz — 54452-06 — — — —
48V/60Hz — 54452-06 — — — 53761-31
100V/50Hz — — — 53900-01 53902-01 —
110V/50Hz 54458-51 54452-01 54469-03 — — 53761-28
120V/50Hz — — — 53900-07 53902-13 —
120V/60Hz 54458-51 54452-01 54469-03 53900-01 53902-01 53761-28
220V/50Hz 54458-52 54452-07 54452-07 — — 53761-29
240V/60Hz 54458-52 54452-07 54452-07 53900-05 53902-14 53761-26
440V/50Hz — — — — — 53761-30
480V/60Hz — — — — — 53761-27
6VDC — — 54469-05 53900-02 53902-10 —
12VDC 54458-54 54452-02 54469-01 53900-03 53902-11 —
24VDC 54458-50 54452-03 54469-02 53900-04 53902-12 —
110VDC — — 54469-06 — — —
OPTIONAL CONNECTORS CC CE, CF, CY
DIN Plug Standard Standard
1/2" NPT Conduit 1V2 1V3
6 m (10 ft.) Molded Cord 1V1 1V5
Cable Grip with Indicator Light:
12VDC or AC 1C1 —
24VDC or AC 1C2 1V4
120VDC or AC 1C3 1VB
220VDC or AC 1C4 —
Replacement Coils
For replacement connectors and bases, please contact Technical Services.
Connector Options for Standard Operators
* CF operator is equipped with fluorocarbon elastomer as standard.
