66 DS679F1
CS42L51
Function:
The level of the shelving treble gain filter is set by Treble Gain Level. The level can be adjusted in 1.5 dB
increments from +12.0 to -10.5 dB.
Bass Gain Level (BASS[3:0])
Default: 1000 dB (No Bass Gain)
Function:
The level of the shelving bass gain filter is set by Bass Gain Level. The level can be adjusted in 1.5 dB in-
crements from +10.5 to -10.5 dB.
6.18 AOUTx Volume Control:
AOUTA (Address 16h) & AOUTB (Address 17h)
Note: The DATA_SEL[1:0] bits in reg09h must be set to ‘01’b to enable function control in this register.
AOUTX Volume Control (AOUTX_VOL[7:0])
Default = 00h
Function:
The analog output levels can be adjusted in 0.5 dB increments from +12 to -102 dB as dictated by the DAC
Soft and Zero Cross bits (DACX_SZC[1:0]). Levels are decoded in unsigned binary as described in the table
above.
Note: When the limiter is enabled, the AOUT Volume is automatically controlled and should not be ad-
justed manually. Alternative volume control may be achieved using the PCMMIXx_VOL[6:0] bits.
Binary Code Gain Setting
0000 +12.0 dB
··· ···
0111 +1.5 dB
1000 0 dB
1001 -1.5 dB
··· ···
1111 -10.5 dB
7 6 5 4 3 2 1 0
AOUTx_VOL7 AOUTx_VOL6 AOUTx_VOL5 AOUTx_VOL4 AOUTx_VOL3 AOUTx_VOL2 AOUTx_VOL1 AOUTx_VOL0
Binary Code Volume Setting
0001 1000 +12.0 dB
··· ···
0000 0000 0 dB
1111 1111 -0.5 dB
1111 1110 -1.0 dB
··· ···
0011 0100 -102 dB
··· ···
0001 1001 -102 dB
