52
DS679F1
CS42L51
6.4
Interface Control (Address 04h)
SDOUT to SDIN Loopback (SDOUT->SDIN)
Default: 0
0 - Disabled; SDOUT internally disconnected from SDIN
1 - Enabled; SDOUT internally connected to SDIN
Function:
Internally loops the signal on the SDOUT pin to SDIN.
Master/Slave Mode (M/S)
Default: 0
0 - Slave
1 - Master
Function:
Selects either master or slave operation for the serial port.
DAC Digital Interface Format (DAC_DIF[2:0])
Default = 000
Function:
Selects the digital interface format used for the data in on SDIN. The required relationship between the
Left/Right clock, serial clock and serial data is defined by the Digital Interface Format and the options are
detailed in the section
“Digital Interface Formats” on page 40
.
7
6
5
4
3
2
1
0
SDOUT->SDIN
M/S
DAC_DIF2
DAC_DIF1
DAC_DIF0
ADC_I²S/LJ
DIGMIX
MICMIX
DAC_DIF[2:0]
Description
Figure
000
Left-Justified, up to 24-bit data
001
I²S, up to 24-bit data
010
Right-Justified, 24-bit data
011
Right-Justified, 20-bit data
100
Right-Justified, 18-bit data
101
Right-Justified, 16-bit data
110
Reserved
-
100
Reserved
-
