48 DS679F1
CS42L51
1Ah Limiter Con-
fig & Release
Rate LIMIT_EN LIMIT_ALL LIM_RRATE
5
LIM_RRATE
4
LIM_RRATE
3
LIM_RRATE
2
LIM_RRATE
1
LIM_RRATE
0
p 69
default
0 1 1 1 1 1 1 1
1Bh Limiter Attack
Rate Reserved Reserved LIM_ARATE5 LIM_ARATE4 LIM_ARATE3 LIM_ARATE2 LIM_ARATE1 LIM_ARATE0
p 70
default
0 0 0 0 0 0 0 0
1Ch ALC Enable
& Attack Rate ALC_ENB ALC_ENA ALC_ARATE
5
AALC_RATE
4
ALC_ARATE
3
ALC_ARATE
2
ALC_ARATE
1
ALC_ARATE
0
p 70
default
0 0 0 0 0 0 0 0
1Dh ALC Release
Rate Reserved Reserved ALC_RRATE
5
ALC_RRATE
4
ALC_RRATE
3
ALC_RRATE
2
ALC_RRATE
1
ALC_RRATE
0
p 71
default
0 0 1 1 1 1 1 1
1Eh ALC Thresh-
old MAX2 MAX1 MAX0 MIN2 MIN1 MIN0 Reserved Reserved
p 71
default
0 0 0 0 0 0 0 0
1Fh Noise Gate
Config NG_ALL NG_EN NG_BOOST THRESH2 THRESH1 THRESH0 NGDELAY1 NGDELAY0
p 72
default
0 0 0 0 0 0 0 0
20h Status Reserved SP_CLKER
R
SPEB_OVFL SPEA_OVFL PCMA_OVFL PCMB_OVFL ADCA_OVFL ADCB_OVFL
p 73
default
0 0 0 0 0 0 0 0
21h Charge Pump
Frequency CHRG_
FREQ3
CHRG_
FREQ2
CHRG_
FREQ1
CHRG_
FREQ0
Reserved Reserved Reserved Reserved
p 74
default
0 1 0 1 0 0 0 0
Addr Function 7 6 5 4 3 2 1 0
