Hardware kit #1 hardware kit #2, Hardware kit #3, Hardware kit #4 – Rugged Ridge PowerTop Kit, 07-14 Jeep Wrangler Unlimited (JK), Black User Manual
Page 8
HARDWARE KIT #1
HARDWARE KIT #2
(2) 1/2x3 Hex Bolt
(4) 1/2x1.5
Washer
(6) 1/2 Nut
(2) Rear
Guard
Bracket
(2) 5/16 Hex
Bolt
(2) Foam
Tape
(6) 5/16 Tapped Hole Plate
(16) 5/16
Washer
(6) 5/16 Button
Head Bolt
(2) 1/2x2.5 Hex Bolt
(4) #8x.625 Sheet
Metal Screw
(4) Rubber
Grommet
(2) Rear Mounting
Bracket L&R
Page 6
The hardware is organized into 7 kits. The appropriate kit needed will be highlighted at the
beginning of each section in the Power Top instructions.
(2) 1/4x1 Button
Head Bolt
(4) 1/4x.5 Flat
Head Bolt
(2) 1/4
Nut
HARDWARE KIT #3
(10) Zip Tie
(2) #8x.625 Sheet
Metal Screw
(4) #10x.5 Button
Head Bolt
(2) Trim Clip
HARDWARE KIT #4
