Rugged Ridge PowerTop Kit, 07-14 Jeep Wrangler Unlimited (JK), Black User Manual
Page 19
SECTION - E - Electrical
Section E
Page 17
©2012
BATTERY
SWITCH
HYDRAULICS
TAIL LIGHT
LIMIT SWITCHES
HYDRAULICS
BATTERY
SWITCH
NOTICE
NOTICE
For right hand vehicles, the wires will need to be installed throughout the
right side of the vehicle.
Section Description- This section will illustrate how to install the electrical harness for the
Power Top.
Tool Needed -
Socket wrench (7/16”, 3/8”, 1/2”)
Drill (9/64”) for vehicles 2011+
Wrench (3/4”, 1/2”, 10mm)
Utility knife
Phillips head screwdriver
Tree Fastener Remover
Hardware Kit - #4
Carefully read and understand all instructions before proceeding.
