Remove the rubber seal from the body tub above the

rear door striker bar.

Hard top owners only - Remove

nut plates used to secure the hard top, then skip to

SECTION B.

3

Soft top owners - Refer to owners manual for

instructions on lowering factory top. Once open,

unscrew the shoulder bolts fastening it to the vehicles

roll bars. Remove the canvas from assembly.
Hard top owners - Refer to owners manual for

instructions on removing factory hard top. Skip to

STEP 3 once hard top is removed.

Hardtop owners will need to purchase

a factory header, tailgate bar and tailgate bar retainers

L&R.

These factory parts are required.
Header - 68003646AA

Tailgate Bar - 55395757AC

Tailgate Bar Retainer Right- 55395760AB

Tailgate Bar Retainer Left- 55395761AB

We recommend that you save all parts

and hardware if you ever choose to re-install the

factory top.

Remove the front

and rear door surrounds from each

side of the vehicle.

Section A

Page 8

SECTION - A - Preparing for Installation - Removal of Factory Soft/Hard Top

1

2

©2012

NOTICE

NOTICE

NOTICE

Section Description- This section will show you how to remove the factory soft/hard top in

preparation for installing the Power Top.

Tool Needed -

Phillips head screw driver

Torx bit socket wrench (T30)

Hardware Kit - No hardware needed

Carefully read and understand all instructions before proceeding.
