Rugged Ridge PowerTop Kit, 07-14 Jeep Wrangler Unlimited (JK), Black User Manual
Page 32
Section G
Page 30
Position your canvas on top of your vehicle so that the
interior side faces up. Pull locations 2 (indicated in Step
5 image) towards the top of the windshield.
Pull the canvas p-channel into the channel at the front of
the header.
Use both the center notch in the
p-channel and the notch in the header to center the
top.
9
10
©2012
Pull the steel cable through the sewn sleeve by pulling
on the opposite side of the string found at locations 2.
Double check that the string is tightly
secured
to the steel cable before pulling.
Insert the abrasion guard into it’s pocket found near
locations 1.
7
8
NOTICE
Find locations 1 (indicated in Step 5 image) of the
canvas. Locate the feeder string that is strung through
the sewn sleeves.
DO NOT PULL! Tie a strong knot
through the eyelet of the cable.
6
Lay out Power Top canvas with the interior side up.
5
1
2
1
2
