Rugged Ridge PowerTop Kit, 07-14 Jeep Wrangler Unlimited (JK), Black User Manual
Page 26
Section E
Page 24
©2012
2012+ Jeep® JK ONLY. Attach the circuit breaker to
the plastic tray that holds the battery.
2012+ Jeep® JK ONLY. Position circuit breaker on the
plastic battery tray and mark guide holes for drilling.
2012+ Jeep® JK ONLY. Drill into the plastic battery tray
using a 9/64 drill bit.
Cutting Hazard: Avoid pressure & heat on bit.
Use gloves and eye protection.
40
38
39
#8x.625 Sheet
Metal Screw
2007-2011 Jeep® JK ONLY. Attach the wire to the
battery’s positive side.
Proceed to Step 42.
Shock/Fire/Chemical Hazard: Confirm area
free from gasoline and other flammable
vapors. Avoid bridging terminals with metal
tools. Wear gloves and eye protection.
37
WARNING
!
CAUTION
!
2007-2011 Jeep® JK Only. Strap the circuit breaker
with zip ties.
36
Fasten the wire with zip ties along the vehicle electrical
harness located along the firewall.
2012+ Jeep® JK
proceed to Step 38.
35
