Agilent E1439 Programmer's Reference
Functions listed alphabetically
clockSetupPtr points to the current value of clockSetup.
AGE1439_CUSTOM_CLOCK_SETUP is returned from age1439_clock_setup_get when low-
level clock configuration functions are used to set up clocks to a non-standard configuration.
Example
The program multichan.exe example program provides an example of how to correctly set up a
multi-module system with synchronous clocks.
Return Value
AGE1439_SUCCESS indicates that a function was successful.
Values other than AGE1439_SUCCESS indicate an error condition or other important status
condition. To determine the error message, pass the return value to
“age1439_error_message” on
page 102 .
Effect on Active Measurement
age1439_clock_setup aborts any measurement in progress.
See Also
“Commands which halt active measurements” on page 198 , “Default values” on page 201 ,
“age1439_init” on page 132 , “age1439_clock_fs” on page 76 , “age1439_clock_recover” on
page 77 , “age1439_ext_sample_sync” on page 104 , “Using clock and sync” in chapter 3 ,
“Managing multiple modules” in chapter 3
Receive sync from master
AGE1439_FRNT_REAR_SLAV_EXT_REF
ADC_CLK VCXO_EXT_REF
VCXO VCXO_ON
ADC_DIVIDER DIVIDE_BY_38
REFERENCE_PRESCALER PRESCALE_BY_1
VXI_CLK_OUTPUT FRONT_PANEL_CLOCK
REFERENCE_CLOCK FRONT_PANEL_CLOCK
FRONT_PANEL_CLOCK SMB_CLOCK
SMB_CLOCK_OUTPUT CLOCK_OFF
SYNC_CLOCK SMB_CLOCK
SYNC_OUTPUT SYNC_OUT_BOTH
SYNC_DIRECTION FRONT_TO_REAR
