4
Installing the Agilent E1439
To install the Agilent E1439
4. Set the mainframe’s power switch to off (0).
Caution
Installing or removing the module with power on may damage components in the module.
5. Place the module’s card edges (top and bottom) into the module guides in the
slot.
6. Slide the module into the mainframe until the module connects firmly with
the backplane connectors. Make sure the module slides in straight and that the
insertion/extraction levers are pressed parallel to the front panel.
0
1
Logical Address
