Agilent E1439 Programmer's Reference
Functions listed alphabetically
Parameters
id
is the VXI instrument session pointer returned by the age1439_init function.
adcLevel
is used to set the triggering signal threshold when using the ADC trigger source. This threshold is
(full scale × adclevel/2048), where
−2048 ≤adclevel ≤2047. There is hysteresis around the
threshold in order to prevent multiple triggers from a single threshold crossing. Hysteresis is 20
ADC counts, or about 1% full scale.
Use
to set the maximum allowable level.
Use
to set the minimum allowable level.
Use
to set the default ADC trigger threshold.
An accurate value of full scale (in volts) can be found by:
full scale = (age1439_data_scale_get * 2^N)/k
where N = 15 if age1439_data_resolution == AGE1439_12_BIT
N = 29 if age1439_data_resolution == AGE1439_24_BIT
and k = 2 if age1439_filter_decimate == AGE1439_DECIMATE_SHIFT
k = 2 if age1439_data_type == AGE1439_REAL and age1439_frequency_center is non-zero
k = 1 otherwise
adcLevelPtr
points to the current value of the adclevel parameter.
trigDelay
is the time delay, in units of output samples, between when a trigger is received and the first data
point in the output data.
selects the minimum allowable trigger delay.
selects the maximum allowable trigger delay.
sets the default trigger delay.
Negative values indicate a pre-trigger condition where samples prior to the trigger event are
included in the output data. The amount of pre-trigger delay is limited to the number of samples
which can be saved in the buffer memory. See the age1439_data_setup function description for
the number of bytes used per sample. The delay limits depend on the data type as follows:
If trigDelay is <
(Pre-trigger) a bad parameter error is set.
trigDelayPtr
points to the current value of the of delay.
genTrig
determines whether a module may generate a trigger.
enables triggering.
Trigger delay in output samples (DRAMsize in bytes)
24 bit complex
24 bit real
12 bit complex
12 bit real
Post trigger
2^31
−1
2^31
−1
2^31
−1
Pre-trigger
48−(DRAMsize/6)
48−(DRAMsize/3)
48−(DRAMsize/1.5)
