34
Using the Agilent E1439
Managing multiple modules
Managing multi-module systems
Note
The
symbol indicates a 50 ohm terminator, which is required on unused SMB connectors in
systems using front panel distribution
Module #1 -
internal reference” on page
82
Module #2 -
phase locked to master” on
page 81
Module #1 -
phase locked to external
reference” on page 81
Module #2 -
phase locked to master” on
page 81
Module #1 -
internal reference” on page
80
Module #2 -
phase locked to master” on
page 81
Module #1 -
phase locked to external
reference” on page 81
Module #2 -
phase locked to master” on
page 81
Internal clock and SYNC distribution
using VXI backplane ECL trigger lines.
External reference and SYNC distribution
using VXI backplane ECL trigger lines.
Slot
0
Contr
oller
Slot
0
Contr
oller
Backplane
Backplane
10 MHz
frequency
reference
1
2
1
2
Internal clock and SYNC distribution using
front panel SMB clock and SYNC
extender connections.
External reference and SYNC distribution using
front panel SMB clock and SYNC
extender connections.
Slot
0
Contr
oller
Slot
0
Contr
oller
10 MHz
frequency
reference
1
2
1
2
