Agilent E1439 Programmer's Reference
Functions listed alphabetically
age1439_sync_direction
Selects front or rear panel availability of the sync signal. This description also includes the query
function:
age1439_sync_direction_get
VXIplug&play Syntax
#include "age1439".h
ViStatus age1439_sync_direction(ViSession id, ViInt16 syncDirection);
ViStatus age1439_sync_direction_get(ViSession id, ViPInt16 syncDirectionPtr);
Note
This command should be used only for specialized custom clock requirements. Most useful clock
setups can be supplied by
.
Description
This function determines whether the front or rear panel sync signal is available to the other panel.
Parameters
id
is the VXI instrument session pointer returned by the age1439_init function.
syncDirection
specifies that front panel sync signal be available on the
VXI backplane (rear panel).
specifies that the VXI backplane sync signal be available
on the front panel SMB sync connectors.
syncDirectionPtr
Returns a pointer to the current value of syncDirection.
Return Value
AGE1439_SUCCESS indicates that a function was successful.
Values other than AGE1439_SUCCESS indicate an error condition or other important status
condition. To determine the error message, pass the return value to
.
See Also
,
“age1439_sync_output” on page 180
,
“age1439_sync_clock” on page 178
,
