170
Agilent E1439 Programmer's Reference
Functions listed alphabetically
age1439_self_test
Performs a self-test and returns the result of that self test.
VXIplug&play Syntax
#include "age1439".h
ViStatus age1439_self_test(ViSession id, ViPInt16 testResult, ViChar testMessage[]);
Description
The Agilent E1439 self test includes the following tests:
• Digital: verifies the integrity of paths from LO chip through the filters to the memory
controller.
• Serial: verifies the integrity of serial setup path for each board.
• Memory: fills the entire DRAM then verifies that all the data is correct.
• Analog: verifies that auto zero adjust is working and that the input is triggering.
• Clock: verifies that the oscillator is working properly.
• Fiber: performs five-second internal fiber verification.
Parameters
id is the VXI instrument session pointer returned by the age1439_init function.
testMessage points to the self test status message string up to 256 characters long.
Note
For this parameter you must allocate a character array of at least 256 characters AGE1439_STR_
LEN_MIN , including the null byte, prior to calling this function in any programming language.
testResult points to the instrument numeric error code.
Possible test result values are:
Error
Message
Error Code
(hex)
Self Test
Status Message
AGE1439_ST_SUCCESS 0x000 self test successful
AGE1439_ST_HARDWARE_FAIL 0x001 hardware failure
AGE1439_ST_SERIAL1_FAIL 0x002 serial 1 test failed
AGE1439_ST_SERIAL2_FAIL 0x004 serial 2 test failed
AGE1439_ST_CLOCK_FAIL 0X008 95 MHz clock test failed
AGE1439_ST_MEMORY_FAIL 0x020 memory test failed
AGE1439_ST_DIGITAL1_FAIL 0x040 real data path failed
AGE1439_ST_DIGITAL2_FAIL 0x080 complex data path failed
