Agilent E1439 Programmer's Reference
Functions listed alphabetically
data type
data
resolution port
transfer
width xfers 1 sequence 2
real 12 bit VME 16 bit 1 R
0
[11:0] |Z4
R
1
[11:0] |Z4 ...
complex 12 bit VME 16 bit 2 R
0
[11:0] |Z4
Q
0
[11:0] |Z4
R
1
[11:0] |Z4
Q
1
[11:0] |Z4 ...
real 24 bit VME 16 bit 2 R
0
[23:8]
R
0
[7:0] |Z8
R
1
[23:8]
R
1
[7:0] |Z8 ...
complex 24 bit VME 16 bit 4 R
0
[23:8]
R
0
[7:0] |Z8
Q
0
[23:8]
Q
0
[7:0] |Z8
R
1
[23:8]
R
1
[7:0] |Z8 ...
real 12 bit LBUS 8 bit 2 R
0
[11:4]
R
0
[3:0] |Z4
R
1
[11:4]
R
1
[3:0] |Z4 ...
complex 12 bit LBUS 8 bit 4 R
0
[11:4]
R
0
[3:0] |Z4
Q
0
[11:4]
Q
0
[3:0] |Z4
R
1
[11:4]
R
1
[3:0] |Z4 ...
real 24 bit LBUS 8 bit 4 R
0
[23:16]
R
0
[15:8]
R
0
[7:0]
Z8
R
1
[23:16]
R
1
[15:8] ...
complex 24 bit LBUS 8 bit 8 R
0
[23:16]
R
0
[15:8],
R
0
[7:0]
Z8,
Q
0
[23:16]
Q
0
[15:8]
Q
0
[7:0]
Z8
R
1
[23:16]
R
1
[15:8] ...
