35
Using the Agilent E1439
Managing multiple modules
Managing multi-mainframe systems
Module #1 - “Front slave,
phase locked to master” on
page 81
Module #2 - “Front master,
internal reference” on page
80
Module # 3 - “Front slave,
phase locked to master” on
page 81
Module #4 - “Front slave,
phase locked to master” on
page 81
Module #1 - “Front slave,
phase locked to master” on
page 81
Module #2 - “Front master,
internal reference” on page 80
Module #3 - “Front slave,
phase locked to master” on
page 81
Module #4 - “Front slave,
phase locked to master” on
page 81
Sharing clock and SYNC among several
modules via front panel distribution.
Slot
0
Contr
oller
1 2 3 4
VXI Mainframe A VXI Mainframe B
Clock and SYNC distribution using front panel
extender connections within and between mainframes.
Slot
0
Contr
oller
Slot
0
Contr
oller
1 2 3 4
