Agilent E1439 Programmer's Reference
Functions listed alphabetically
AGE1439_ADC inserts a 0.2 µF capacitor between the input connector and the 50 Ohm buffer
amplifier.
couplingPtr points to the current value of the coupling parameter for an Agilent E1439 or group of
Agilent E1439s.
range is a range index number which is transformed to a full scale voltage value. This function always
sets only the IF signal path range even if signalPath is set to AGE1439_BB_PATH. In baseband
mode the range is fixed at -21 dBm.
AGE1438_RANGE_MAX sets the range to the maximum allowable.
AGE1439_RANGE_MIN sets the range to the minimum allowable.
Signal inputs with an absolute value larger than full scale generate an ADC overflow error.
Range values are as follows.
Variable Range Index
Full Scale
(dBm)
Full Scale
Voltage (Vp)
AGE1439_RANGE_MAX 48
AGE1439_RANGE_48 48 12 1.26
AGE1439_RANGE_47 47 11 1.12
AGE1439_RANGE_46 46 10 1
AGE1439_RANGE_45 45 9 .891
AGE1439_RANGE_44 44 8 .794
AGE1439_RANGE_43 43 7 .708
AGE1439_RANGE_42 42 6 .631
AGE1439_RANGE_41 41 5 .562
AGE1439_RANGE_40 40 4 .501
AGE1439_RANGE_39 39 3 .447
AGE1439_RANGE_38 38 2 .398
AGE1439_RANGE_37 37 1 .355
AGE1439_RANGE_36 36 0 .316
AGE1439_RANGE_35 35 −1 .282
AGE1439_RANGE_34 34 −2 .251
AGE1439_RANGE_33 33 −3 .224
AGE1439_RANGE_32 32 −4 .12
AGE1439_RANGE_31 31 −5 .178
AGE1439_RANGE_30 30 −6 .159
AGE1439_RANGE_29 29 −7 .141
AGE1439_RANGE_28 28 −8 .126
AGE1439_RANGE_27 27 −9 .112
AGE1439_RANGE_26 26 −10 .1
AGE1439_RANGE_25 25 −11 .089
AGE1439_RANGE_24 24 −12 .0794
AGE1439_RANGE_23 23 −13 .0708
AGE1439_RANGE_22 22 −14 .0631
