83
Agilent E1439 Programmer's Reference
Functions listed alphabetically
Multi-module external sample setups, set all modules the same
Rear slave, phase locked to master
AGE1439_REAR_SLAV_EXT_REF
ADC_CLK VCXO_EXT_REF
VCXO VCXO_ON
ADC_DIVIDER DIVIDE_BY_38
REFERENCE_PRESCALER PRESCALE_BY_1
VXI_CLK_OUTPUT CLOCK_OFF
REFERENCE_CLOCK VXI_CLOCK
FRONT_PANEL_CLOCK CLOCK_OFF
SMB_CLOCK_OUTPUT CLOCK_OFF
SYNC_CLOCK VXI_CLOCK
SYNC_OUTPUT SYNC_OUT_VXI
SYNC_DIRECTION REAR_TO_FRNT
Front sync, external sample clock, wired-OR sync
AGE1439_FRNT_SYNC_EXT_SAMP
ADC_CLK EXT_SAMPLE_CLOCK
VCXO VCXO_OFF
ADC_DIVIDER DIVIDE_BY_38
REFERENCE_PRESCALER PRESCALE_BY_1
VXI_CLK_OUTPUT CLOCK_OFF
REFERENCE_CLOCK FRONT_PANEL_CLOCK
FRONT_PANEL_CLOCK BNC_CLOCK
SMB_CLOCK_OUTPUT CLOCK_OFF
SYNC_CLOCK DIVIDED_ADC_CLOCK
SYNC_OUTPUT SYNC_OUT_SMB
SYNC_DIRECTION FRNT_TO_REAR
