71
Agilent E1439 Programmer's Reference
Functions listed alphabetically
most recent trigger event
age1439_trigger_delay_get
−gets the trigger delay time
age1439_trigger_gen
−determines whether a module can generate a trigger
age1439_trigger_gen_get
−gets the trigger generation status
age1439_trigger_magdwell
−specifies the dwell time (in samples) before a
magnitude trigger
age1439_trigger_magdwell_get
−gets the magnitude trigger dwell time in
samples
age1439_trigger_maglevel
−specifies the threshold for a magnitude trigger
age1439_trigger_maglevel_get
−gets magnitude trigger threshold
age1439_trigger_phase_actual_get
−returns a representation of the phase
value of the LO at the most recent trigger point
age1439_trigger_setup
−sets all parameters associated with triggering the
beginning of data collection
age1439_trigger_slope
−selects a positive or negative trigger
age1439_trigger_slope_get
−gets trigger slope
age1439_trigger_type
−determines the trigger type
age1439_trigger_type_get
−gets trigger type
age1439_vcxo
−selects whether the module should use an internal clock
source
age1439_vcxo_get
−gets whether the internal clock source is on or off
age1439_vxi_clock_output
−selects which clock drives the VXI clock
age1439_vxi_clock_output_get
−gets which clock drives the VXI clock
age1439_wait
−facilitates the synchronization and control of multi-module
systems
