131
Agilent E1439 Programmer's Reference
Functions listed alphabetically
age1439_front_panel_clock_input
Specifies the source for the front panel clock. This description also includes the query function:
age1439_front_panel_clock_input_get
VXIplug&play Syntax
#include "age1439".h
ViStatus age1439_front_panel_clock_input(ViSession id, ViInt16 fpClock);
ViStatus age1439_front_panel_clock_input_get(ViSession id, ViPInt16 fpClockPtr);
Note
This command should be used only for specialized custom clock requirements. Most useful clock
setups can be supplied by
age1439_clock_setup .
Description
This function selects a front panel clock source that is used to drive the analog to digital converter
(ADC) for single module operation or when a module is used as the master ADC clock source for
a multi-module system.
Parameters
id is the VXI instrument session pointer returned by the age1439_init function.
fpClock AGE1439_CLOCK_OFF specifies no front panel source.
AGE1439_SMB_CLOCK specifies clock input from the front panel Intermodule Clock/SMB
connectors.
AGE1439_BNC_CLOCK specifies clock input from the front panel Ext Clock/Ref BNC
connector.
fpClockPtr returns a pointer to the current value of fpClock.
Return Value
AGE1439_SUCCESS indicates that a function was successful.
Values other than AGE1439_SUCCESS indicate an error condition or other important status
condition. To determine the error message, pass the return value to
“age1439_error_message” on
page 102 .
See Also
“Commands which halt active measurements” on page 198 , “Default values” on page 201 ,
“age1439_init” on page 132 , “age1439_clock_setup” on page 78 , “Using clock and sync” in
chapter 3
