4.10.2 Overlay / Print Area
The Overlay / Print Area box includes several options:
Defined Area – To define multiple areas, increase the count in the Defined Area field and repeat the
overlay or print area definition steps.
For Print and Overlay – This option applies the defined area to both the print and overlay
processes.
For Overlay Only – The defined are applies only to the overlay process. The entire card prints and
only the overlay is affected.
For Print Only (No Overlay) – The defined are applies only to the print process. Overlay is
disabled.
4.10.3 Security Options
The Security Options area includes the following options:
Visual Security Solutions – Use this field to enable and select a visual security option. When one
of the options is selected, the Overlay/Print Area feature is disabled.
This field presents options based on the orientation of the card in the template. The default value for
all cards is No Visual Security.
Landscape designs offer:
A – Upper Left
B – Upper Right
C – Lower Left
D – Lower Right
Portrait designs offer:
E – Upper Left
F – Upper Right
G – Lower Left
HoloMark – Use this option for hologram security.
