ATI 9700 - Installation Guide (Initial Installation of the ATI 9700)
1.19 Configure Local Terminal or PC
The RS-232 (CONSOLE) terminal port is used during the initial installation startup to connect the ATI 9700 to a
local management device, which can be:
• A terminal (VT-100 compatible)
• A PC with terminal emulation software
The CONSOLE port is a DB9 female socket configured as a DCE, which allows for the direct connection to the
terminal or PC. Refer to ATI Component Specification for a listing of DB9 pin assignments.
The settings for the CONSOLE port are initially configured with the following default values:
Note: Set Flow Control to OFF in order to view the start up sequence from the user terminal.
When using the CONSOLE port, ensure that the terminal emulation software has FLOW
CONTROL disabled.
TABLE 1-5 Default Asynchronous Port Settings
Option Default Option Default
ATTENTION BREAK MAXOQLEN 0 (Unrestricted)
CDCONTROL IGNORE MTU 1500
DATABITS 8 NAME ASYN 0
DEFAULTSERVICE FALSE OUTFLOW HARDWARE
DTRCONTROL ON PAGE 22
ECHO ON PARITY NONE
FLOW HARDWARE PROMPT DEFAULT (CMD>)
HISTORY 30 SECURE ON
INFLOW HARDWARE SERVICE NONE
IPADDRESS NONE SPEED 9600
IPXNETWORK NONE STOPBITS 1
LOGIN ON TYPE VT100
When using an AC-powered terminal or PC, use an RS232 line isolation unit between
the terminal/pc and the RS232 port. For battery-powered devices (laptop) this is not
required.
