Page 33
Duplex configuration
Install the Network Module
1-27
ATI 9700 - Installation Guide (Initial Installation of the ATI 9700)
FIGURE 1-21
Detail of the lock-latch in open position
1.15 Install the Network Module
Note:
This procedure can be applied to any NM supported on the 9700.
The GE3 cards go into Half-Slots 10 and 11. It is recommended that half-slot 10 be filled first (the bottom slot).
1.
Take the card from its antistatic container.
2.
Follow the card installation procedure detailed in section
.
Release
Button
