Allied Telesis 9700 iMAP User Manual
Page 14
Selecting a Site (Office Installation)
Setup Checklist
ATI 9700 - Installation Guide (Initial Installation of the ATI 9700)
1-8
The user has three mounting options available:
•
19” telecom rack front mount
•
19” telecom rack center mount
•
23” telecom rack
The following diagrams illustrate the different mounting options.
FIGURE 1-3
Center mounted 9700 with channel standoffs installed (in bold red)
