AlliedView™-EMS 3.11 QoS Manager User’s Guide Page 96 of 146
Property
Name
Description Valid Values
sent over the port specified by
the port parameter so the VLAN
must contain that port.
Port Specifies the port where
unclassified traffic is sent when
action is sendvlanport. The port
must belong to the VLAN
specified by the vlan parameter.
This can be set by selecting any one of
the following values:
• port 1 - n (n = number of ports
available)
• none
Flow Group
List
Specifies a list of the Flow Groups
currently assigned to this Traffic
Class.
Select from a list of available Flow Group
IDs.
6.7.4 Policies
6.7.4.1 QoS Information Window
Column Name Description
Policy ID Lists the ID of Policies available
Description A brief description of the Policy
Traffic Classes List of Traffic Classes associated with this Policy
6.7.4.2 Add/Modify Policy
Property
Name
Description Valid Values
Policy ID
(cannot be
modified) Specifies the unique identifier for
the Policy. Range: 0-255
Description Specifies a brief description of the
Policy. To set this value, enter an alphanumeric
string from 1-15 characters.
Default Traffic
Class Action Specifies the action to be
performed on traffic that is
processed by the default traffic
class.
This can be set by selecting any one of
the following:
• FORWARD
• FORWARD,SENDMIRROR
• DISCARD
• SENDMIRROR
• SENDMIRROR,SENDVLANPORT
• SENDVLANPORT
Default Traffic
Class Drop
Bandwidth
Determines whether or not to
drop frames exceeding the default
traffic class maximum bandwidth
• yes
• no
